Auto Radial Insertion Machine
Auto Radial Insertion Machine
SKU:
| Attribute | Details |
|---|---|
| Core Components | PLC, Engine, Bearing, Gearbox, Motor, Pressure Vessel, Gear, Pump |
| Warranty | 1 Year |
| Video Outgoing Inspection | Provided |
| Machinery Test Report | Provided |
| Weight (kg) | 1250 |
| Model Number | OFM-2 |
| Product Name | Odd Form Insertion Machine |
| Max PCB Size (mm) | 70 × 70 ~ 300 × 500 (Fixture size: 350 × 500) |
| Transmission Height | Upper 25mm, Bottom 20mm |
| PCB Weight | Max 5 KG |
| Rail | 3 Sections |
| Component Size | Max 50mm (35 × 35mm) |
| Power Supply | Three-phase AC380V, 4.5KW |
| Machine Size (mm) | 1050 × 1680 × 1870 |
